| CPU |
Support for Intel® Core™ Mobile i7 series / Intel® Core™ Mobile i5 series / Intel® Core™ Mobile i3 series PGA988 Processor |
| Chipset |
Intel® HM55 Express Chipset |
| Memory |
Supports DDR3 1600/1333/1066 memory |
| Dual Channel architecture support up to 8GB by 2 DIMM slots |
| Graphics |
Intel® HD Graphics |
| 1*HDMI port |
| 1*VGA port |
| Audio |
Realtek ALC662 6 Channel Audio Codec |
| LAN |
Realtek 8105E/8111E 100M/1000M LAN Controller |
| Expansion slots |
1*PCI Express X16 slot |
| 1*PCI Express X1 slot |
| I/O connectors |
4*SATA 3Gb/s connector |
| 1*front panel connector |
| 1*front audio connector |
| 4*USB 2.0/1.1 connector; 4*USB 2.0/1.1 port |
| 1*COM port |
| 1*PS/2 port |
| 1*VGA port |
| 1*RJ-45 port |
| 1*HDMI port |
| 1*audio jacks |
| Form Factor |
210 x 170mm |
