| CPU |
Supports LGA1366 Intel® Core™ i7 / LGA1366 Intel® XEON |
| Chipset |
Intel® X58+ICH10 |
| Memory |
Supports DDR3 1600/1333/1066MHZ memory |
| Dual Channel architecture support up to 16GB by 2 DIMM slots |
| Audio |
Realtek ALC662 6 Channel Audio Codec |
| LAN |
Realtek 8105E/8111E 100M/1000M LAN Controller |
| Expansion slots |
1*PCI Express X16 slot |
| 1* PCI Express X1 slot |
| 1*PCI slot |
| I/O connectors |
1*IDE connector(Optional) |
| 4* SATA 3Gb/s connector |
| 1*front panel connector |
| 1*front audio connector |
| 2*USB 2.0/1.1 connector |
| 8*USB 2.0/1.1 port |
| 1*2 COM port |
| 1*PS/2 port |
| 1*RJ-45 port |
| 1*LPT port |
| 1*audio jacks |
| Form Factor |
242 x 188mm |
| Packing Include |
1*motherboard;1*SATA Cable;1*Mainboard Driver;1*baffle;1*User Manual;1*IDE Cable(optianal) |
